Savaria Infinity

Commercial
Residential

The Savaria Infinity is a smooth and quiet residential elevator that mixes seamlessly with any home décor. With its self-contained submersible, hydraulic pump and motor, the elevator boasts a small footprint compatible with the Infinity’s customizable, modern design. The elevator also adopts the best high-tech features, including fully-automatic operation, a digital operating panel and a digital floor and directional indicator.

Request a Consultation

Product Features

  • Automatic and illuminated push buttons for easy operations
  • Magnetic floors for automatic leveling at each landing
  • Automatic cabin lighting with four LED down lights for comfort
  • Submersible and variable speed pressure valve for safe travel
  • Emergency alarm and stop buttons in the event of catastrophic failure
  • Battery-operated emergency lowering and lighting and manual emergency lowering button in the event of power failure
  • Basic surface-mount telephone for communication from the cabin
  • Lockable control panel to prevent usage from children or any other unwanted users
  • Slack-rope safety system for security in case of emergency
  • In-use indicator lights on hall station to alert others of operation
  • Recessed plywood floors for added style
  • Cylindrical handrails in cabin for balance during travel
  • Backed by 101 Mobility’s One-Year Limited Service Warranty in addition to manufacturer’s warranty

Technical Specifications

  • Maximum lift height: 50’ (15.24 m)
  • Maximum number of stops: 6
  • Minimum pit depth: 8” (203 mm)
  • Maximum speed: 40 fpm (0.20 m/s)
  • Drive/motor: 1:2 cable hydraulic drive, 3 hp

Product Options

Options:

  • Alphanumeric button marking – Buttons are labeled with letters and symbols, offering an alternative system for operation understanding
  • Cabin ceiling finish – Two different finishes for added style:
    • Standard architectural white
    • White MDF

Additional option to match cabin ceiling finish to wall finish

  • Cabin configurations – Five different cabin configurations for optimum customization:
Type 1
One left-hand or right-hand door
Car size Width Depth Clear opening
36″ x 48″ (914 mm x 1219 mm) 50.5″ (1282.7 mm) 55″ (1397 mm) 36″ (914 mm)
36″ x 54″ (914 mm x 1372 mm) 50.5″ (1282.7 mm) 61″ (1549 mm) 36″ (914 mm)
36″ x 60″ (914 mm x 1524 mm) 50.5″ (1282.7 mm) 67″ (1702 mm) 36″ (914 mm)
40″ x 54″ (1016 mm x 1372 mm) 54.5″ (1384.3 mm) 61″ (1549 mm) 36″ (914 mm)



Type 2
Two doors, 180-degrees from each other
Car size Width Depth Clear opening
36″ x 48″ (914 mm x 1219 mm) 50.5″ (1282.7 mm) 55″ (1397 mm) 36″ (914 mm)
36″ x 54″ (914 mm x 1372 mm) 50.5″ (1282.7 mm) 61″ (1549 mm) 36″ (914 mm)
36″ x 60″ (914 mm x 1524 mm) 50.5″ (1282.7 mm) 67″ (1702 mm) 36″ (914 mm)
40″ x 54″ (1016 mm x 1372 mm) 54.5″ (1384.3 mm) 61″ (1549 mm) 36″ (914 mm)



Type 3
Two doors, 90-degrees from each other
Car size Width Depth Clear Opening
Door B Door C
36″ x 48″ (914 mm x 1219 mm) 52.125″ (1323.975 mm) 55″ (1397 mm) 36″ (914 mm) 34.625″ (879.475 mm)
36″ x 54″ (914 mm x 1372 mm) 52.125″ (1323.975 mm) 61″ (1549 mm) 36″ (914 mm) 34.625″ (879.475 mm)
36″ x 60″ (914 mm x 1524 mm) 52.125″ (1323.975 mm) 67″ (1702 mm) 36″ (914 mm) 34.625″ (879.475 mm)
40″ x 54″ (1016 mm x 1372 mm) 56.125″ (1425.575 mm) 61″ (1549 mm) 36″ (914 mm) 36″ (914 mm)



Type 4
Two doors, 90-degrees from each other
Car size Width Depth Clear Opening
Door A Door B
36″ x 48″ (914 mm x 1219 mm) 52.125″ (1323.975 mm) 55″ (1397 mm) 34.625″ (879.475 mm) 36″ (914 mm)
36″ x 54″ (914 mm x 1372 mm) 52.125″ (1323.975 mm) 61″ (1549 mm) 34.625″ (879.475 mm) 36″ (914 mm)
36″ x 60″ (914 mm x 1524 mm) 52.125″ (1323.975 mm) 67″ (1702 mm) 34.625″ (879.475 mm) 36″ (914 mm)
40″ x 54″ (1016 mm x 1372 mm) 56.125″ (1425.575 mm) 61″ (1549 mm) 36″ (914 mm) 36″ (914 mm)



Type 5
One door, compatible with three different sides of cabin
Car size Width Depth Clear opening
36″ x 48″ (914 mm x 1219 mm) 52.125″ (1323.975 mm) 56.25″ (1428.75mm) 36″ (914 mm)
36″ x 54″ (914 mm x 1372 mm) 52.125″ (1323.975 mm) 62.25″ (1581.15 mm) 36″ (914 mm)
36″ x 60″ (914 mm x 1524 mm) 52.125″ (1323.975 mm) 68.25″ (1733.55 mm) 36″ (914 mm)
40″ x 54″ (1016 mm x 1372 mm) 56.125″ (1425.575 mm) 62.25″ (1581.15 mm) 36″ (914 mm)



  • Cabin entrance trim finish – Two different finishes for added style:
    • Bronze anodized aluminum
    • Clear anodized aluminum
  • Cabin gate style – Eight different styles for optimum customization:
    • Black scissor style
    • Clearfold style – clear anodized frame with clear acrylic inserts
    • Panelfold styles:
      • Bronze anodized frame with all antique white inserts
      • Bronze frame with antique white inserts plus three clear acrylic inserts
      • Clear anodized frame with all antique white inserts
      • Clear anodized frame with antique white inserts plus three clear acrylic inserts
    • Visifold style – bronze frame with bronze acrylic inserts
    • Savaria automatic slim doors (requires 84” (2134 mm)-tall cabin)
  • Cabin lights finish – Four different finishes for added style:
    • Recessed brass down lights
    • Recessed bronze anodized aluminum down lights
    • Recessed clear anodized aluminum down lights
    • Recessed stainless steel down lights
  • Cabin operating panel finish – Four different finishes for added style:
    • Brass
    • Bronze anodized aluminum
    • Clear anodized aluminum
    • Stainless steel
  • Cabin sizes – Four different cabin sizes for optimum customization. Additional option for custom cabin sizes, up to 15 square feet:
    • 36” x 48” x 80” (914 mm x 1219 mm x 2032 mm)
      • Compatible with cabin configuration types 1, 2, 3, 4 and 5
    • 36” x 54” x 80” (914 mm x 1371 mm x 2032 mm)
      • Compatible with cabin configuration types 1, 2, 3, 4 and 5
    • 36” x 60” x 80” (914 mm x 1524 mm x 2032 mm)
      • Compatible with cabin configuration types 1, 2, 3, 4 and 5
    • 40” x 54” x 80” (1016 mm x 1372 mm x 2032 mm)
      • Compatible with cabin configuration types 1, 2, 3, 4 and 5
    • Cabin walls finish – 20 different finishes in six different materials for added style:
      • White MDF
      • Luxury routered white MDF
      • Melamine finishes:
        • Dark Cherry
        • Cherry
        • Candlelight
        • Red Oak
        • Silken Maple
        • Antique White
      • Unfinished veneer finishes:
        • Oak
        • Cherry
        • Maple
        • Birch
      • Red oak raised hardwood finishes:
        • Autumn
        • Cordoba
        • Walnut
      • Maple raised hardwood finishes:
        • Bamboo
        • Merlot
        • Nutmeg
      • Cherry raised hardwood finishes:
        • Bamboo
        • Cordoba
        • Walnut
      • Hall call station finish – Available in rectangular or oval shape as well as four different finishes for added style:
        • Brass
        • Bronze anodized aluminum
        • Clear anodized aluminum
        • Stainless steel
      • Heavy-duty configuration – Cabin configuration boasts a larger capacity. Technical specifications and options:
        • Weight capacity: 1400 lbs (635 kg)
        • Compatible with cabin configuration types 1, 2, 3, 4 and 5
        • Minimum pit depth: 12” (305 mm)
        • Minimum overhead clearance:
          • 92” (2337 mm) for 80” (2032 mm)-tall cabin
          • 96” (2438 mm) for 84” (2134 mm)-tall cabin
          • 108” (2743 mm) for 96” (2438 mm)-tall cabin
        • Optional cabin size:
          • 48” x 60” x 80” (1219 mm x 1524 mm x 2032 mm)
            • Compatible with cabin configuration types 1, 2, 3, 4 and 5
          • Interlocks – Choice of Kwiklock or EMI-Porta elevator door interlocks to ensure secure travel
          • Internal cabin height – Three different internal cabin heights for optimum customization:
            • 80” (2032 mm) – minimum overhead clearance: 92” (2337 mm)
            • 84” (2134 mm) – minimum overhead clearance: 96” (2438 mm)
            • 96” (2438 mm) – minimum overhead clearance: 108” (2743 mm)
          • Keyed hall station – Locks the hall station to prevent usage from children or any other unwanted users
          • Power gate and power door operator – Enables gate and door to open and close automatically with no manual effort for easy boarding and exiting
